The PANEL 14 directional Wi-Fi antenna from Interline is designed for the 2.4 GHz Wi-Fi frequency band and supports all common Wi-Fi standards within this frequency band (IEEE 802.11 b/g/n).
Due to the technically advanced microstrip design of the Wi-Fi panel directional antenna and the gain of 14 dBi, the Wi-Fi antenna is very suitable for stable point-to-point or point-to-multipoint connections over medium distances.
The housing of the Interline PANEL 14 is made of robust, weatherproof, and UV-resistant plastic. Therefore, the Wi-Fi antenna is completely weatherproof and can be used outdoors for long periods without any problems.
The antenna is designed for mounting on a mast or a wall bracket. A pipe clamp (30mm - 50mm) for mast mounting is included in the delivery.
The antenna is connected to your Wi-Fi device via a coaxial antenna cable. You can find a suitable cable for connecting the antenna here in our webshop.
Technical Data:
| Manufacturer / Model: |
Interline / IP-G14-F2425-HV |
| Antenna Type: |
Directional Antenna |
| Gain: |
14 dBi |
| Impedance: |
50 Ohms |
| Frequency Range: |
2.4 GHz
(IEEE 802.11 b/g/n) |
| VSWR: |
max. 1.7 |
| Polarization: |
Horizontal or Vertical (Linear) |
| Beamwidth: |
30° Horizontal
30° Vertical |
| Front to Back Ratio: |
min. 20 dB |
| XPD (Cross Polarization Discrimination): |
min. 24 dB |
| Connector: |
N-Female |
| Application Area: |
Indoor and Outdoor |
| IP Rating: |
IP64 |
| Max. Wind Load: |
52N (@170 km/h) |
| Surge Protection: |
DC Grounded |
| Dimensions: |
20 cm x 19.6 cm x 2 cm |
| Weight: |
840 g incl. mounting accessories |
| Color: |
White / Gray |
Package Contents:
| 1 x Interline PANEL 14 - 2.4 GHz directional antenna |
| 1 x Mounting bracket incl. pipe clamp |
