The DMM4-6-60-2SP portable antenna is an innovative antenna design which provides 4x4 MiMo function for 4G/5G with fallback to 3G/2G . The DMM4-6-60-2SP antenna is a future proof solution for Cat 18/20 4G and 5G devices. Incorporating four separately fed, ultra wide band elements for 617-960 / 1710- 6000MHz in a single housing, the DMM4 provides a 4x4 MiMo function. It can also provide 2x 2x2 MiMo function for a router with dual modems, each requiring a 2x2 antenna system.
The DMM is an cost effective value added product for network operators and service providers ensuring a stable link with improved data rates for subscribers thereby improving satisfaction and retention. The antenna has a peak gain of 5dBi and is equipped with 4 x 2m RG174 antenna cable with SMA male connector.
Technical Data:
| Manufacturer / Model: |
Panorama Antennas / DMM4-6-60-2SP |
| Type: |
4x4 MIMO Omni Antenna |
| Gain: |
2 - 5dBi |
| Impedance: |
50 Ohm |
| Frequency: |
698-960 MHz (2G, 4G)
1710-6000 MHz (2G, 3G, 4G, 5G) |
| Polarisation: |
Vertical (Linear) |
| VSWR: |
max. 2.5 |
| Beamwidth: |
360° Horizontal |
| Cable: |
4 x 2m, RG-174 |
| Connector: |
SMA male |
| Appliance: |
Indoor |
| Dimensions Antenna: |
18.4cm (H) x 18,5cm (W) |
| Color: |
Black |
Scope of delivery
| 1 x Panorama Antennas DMM4-6-60-2SP |
