The TP-Link EAP625-Outdoor HD is a powerful and weatherproof dual-band access point specifically designed for outdoor use. With its robust construction and IP67 certification, the device withstands even the harshest weather conditions, including rain, snow, and dust, while consistently providing a stable and reliable Wi-Fi connection.
Equipped with the latest WiFi 6 (802.11ax) technology, the EAP625-Outdoor HD offers high speeds of up to 1800 Mbps. This includes 1201 Mbps in the 5 GHz band and 574 Mbps in the 2.4 GHz band. By utilizing OFDMA and MU-MIMO, the access point can efficiently serve multiple devices simultaneously, which is especially beneficial in high-density environments such as events, public parks, or large corporate campuses.
The access point is equipped with intelligent mesh technology, enabling seamless connections between multiple EAPs without users noticing any interruptions. This allows you to reliably cover large areas with Wi-Fi. Additionally, the sleek, unobtrusive design ensures that the TP-Link EAP625-Outdoor HD blends seamlessly into any environment.
Installation and Management:
The installation and management of the TP-Link EAP625-Outdoor HD are particularly easy thanks to its integration into the Omada SDN platform. This allows for centralized network management through an intuitive user interface or a mobile app. With support for Power over Ethernet (PoE), installation is further simplified, as only a single cable is needed for both power and data transmission.
Centralized Management - Omada:
Omada is the central control and management software for this system. The Omada Controller software is available as a free download for Windows, macOS, and Linux, allowing the Controller software to run on a computer integrated into the network. Alternatively, TP-Link also offers standalone controllers with pre-installed Omada Controller software. The Omada system can then be managed via its own web interface or with an Omada Cloud account through the Omada app, available for Android and iOS. This setup also allows you to access your Omada network remotely. All integrated Omada access points and Omada-compatible switches are centrally managed via Omada, enabling quick and clean administration of your network. Additional access points can be added quickly and easily.
Technical Data:
| Manufacturer / Model: | TP-Link / EAP625-OUTDOOR HD |
| Antennas: | 2 x external dual-band omnidirectional antenna (2.4GHz with 3 dBi, 5GHz with 5 dBi) |
| Wi-Fi Frequency Band: | 2.4 GHz / 5GHz |
| Wi-Fi Standards: | IEEE 802.11a/b/g/n/ac/ax |
| Data Rate: | 2.4 GHz: 574 Mbps / 5 GHz: 1201 Mbps |
| Multiple SSID: | 16 |
| PoE: | IEEE 802.3 at |
| Security: | WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Power Input: | 48V/0.5A Passive PoE (PoE adapter not included) |
| Dimensions: | 280.4 × 182.2 × 56.9 mm |
| Operating Temperature: | 0°C - +40°C |
| Humidity: | -30 - 70%, non-condensing |
Package Contents:
| 1 x TP-Link Access Point EAP625-Outdoor HD |
| 1 x Wall Mounting Kit |
