The EdgeRouter 6P / ER-6P from Ubiquiti Networks is the next generation of the EdgeMAX platform and provides security and management functions in a compact and silent metal enclosure. Powered by a proprietary and intuitive graphical user interface, EdgeOS™, EdgeRouters can easily be configured for routing, security, and management features required to efficiently run your network. Accessed via a network port and web browser, the user-friendly interface provides intuitive management with a virtual view of the ports, displaying physical connectivity, speed and status. The Dashboard displays detailed statistics: IP information, MTU, transmit and receive speeds, and status for each physical and virtual interface. For advanced network professionals, an integrated CLI is available for quick and direct access using familiar commands.
PoE
The EdgeRouter 6P offers a PoE option to all the five RJ45 Gigabit Ethernet ports. It is switchable between no PoE and 24V.
DHCP Server
Set up multiple DHCP servers to assign IP ranges in different subnets on the different interfaces. Easily control dynamic and static IP addressing for your network devices.
Secure Your Network
Firewall Policies Organize the rules you apply in the order you specify. Firewall Groups Apply the policies to groups filtered by IP address, network address, or port number.
NAT Rules
The EdgeRouter changes packet addressing based on your customized source and destination NAT rules.
Direct Traffic Flow
Interfaces Each Gigabit port functions as an independent interface. You can also configure Virtual Local Area Network (VLAN) interfaces to meet your network segmentation requirements. Routing Configure static routes and dynamic routing protocols to effectively manage the routes used bythe EdgeRouter. With these capabilities and more, EdgeRouter provides the centralized control you need to optimize the performance and reliability of your network.
Monitoring Tools & User Accounts
You can conveniently access your EdgeRouter using unique administrator and operator accounts and track network activity and device status such as Ping, Discover, Trace, Log Monitor and Packet Capture.
Technical Data:
| Manufacturer / Product: |
Ubiquiti Networks / EdgeRouter 6P (ER-6P) |
| Networking Interface Management: |
(1) RJ45 Serial Port
(6) Ethernet Ports (Default eth0) |
| Networking Interface Interface: |
(5) 10/100/1000 RJ45 Ports with PoE
(1) 1 Gbps SFP Port |
| Power: |
External AC Power Adapter, 60W (24V, 2.5A) |
| Power Input: |
110 - 240VAC |
| Button: |
Reset |
| LEDs: |
Data Ports: Speed/Link/Activity, PoE
SFP Data Port: Link/Activity |
| Processor: |
4-Core 1 GHz, MIPS64 |
| Systm Memory: |
1 GB DDR3 RAM |
| Flash Memory: |
4 GB eMMC, 8 MB SPI NOR |
| Performance: |
64 Bytes, 3.400.000 pps |
| Interface/Encapsulation: |
Ethernet, 802.1q VLAN, PPPoE, GRE, IP in IP, Bridging, Bonding (802.3ad) |
| Addressing: |
Static IPv4/IPv6 Addressing DHCP/DHCPv6 |
| Routing: |
Static Routes, OSPF/OSPFv3, RIP/RIPng, BGP (with IPv6 Support), IGMP Proxy, MPLS |
| Security: |
ACL-Based Firewall, Zone-Based Firewall, Application Identification with Deep Packet Inspection (DPI), NAT |
| VPN: |
IPSec Site-to-Site and Remote Access, OpenVPN Site-to-Site and Remote Access, PPTP Remote Access, L2TP Remote Access, PPTP Client |
| Services: |
DHCP/DHCPv6 Server, DHCP/DHCPv6 Relay, Dynamic DNS, DNS Forwarding, VRRP, RADIUS Client, Web Caching, PPPoE Server |
| QoS: |
FIFO, Stochastic Fairness Queueing, Random Early Detection, Token Bucket Filter, Deficit Round Robin, Hierarchical Token Bucket, Ingress Policing |
| Management: |
Web UI, Ubiquiti Network Management System (UNMS), CLI (GUI, Console, SSH, Telnet), SNMP, NetFlow, LLDP, NTP, UBNT Discovery Protocol, Syslog |
| max. Power Consumption: |
16 W (Excludes PoE Output) |
| Dimensions: |
22,9 x 13,6 x 3,1cm |
| Weight: |
0,730 kg |
| Operating Temperature: |
-10°C bis +50°C |
| Humidity: |
10 - 90% non-condensing |
| Certifications: |
CE, FCC, IC |
Scope of delivery:
| 1 x Ubiquiti EdgeRouter 6P (ER-6P) |
| 1 x 24V/2.5A Power Adapter |
| 1 x Mounting Accessories |
